PR-4100 Folding Squat Rack

PR-4100 Folding Squat Rack - 21.5

PR-4100 Folding Squat Rack - 21.5

PR-4100 Folding Squat Rack - 41

OVERVIEW

PRODUCT DIMENSIONS

PR-4100 Folding Squat Rack Informational

Rack Upright Height

92.3"
Material

3x3" 11-Gauge Steel
21.5” Inside Length

18.9"
21.5” Inside Width

42.1”
21.5” Overall Width

48”
41” Inside Length

37.4”
41” Inside Width

42.1”
41” Overall Width

48"
Rackable Capacity

When Properly Mounted, 1,000lbs

PRODUCT FEATURES

Saves Space

The 21.5” design folds in on itself to take up just 6” from the wall, and the 41” options folds left/right to take up 24” from the wall.
Attachments

Compatible with add-ons, such as landmine and dip attachments and other J-cup styles.
Heavy-Duty

11-gauge steel rack is tough enough for movements like kipping pull-ups and muscle-ups.
Hole Spacing

1” hole spacing through bench press and pull area allows for dialed-in liftoff height.
Protective Caps

Caps on bottom of uprights ensures smoother setup and protects floors.
Clevis Pins

Heavy-duty pull pins allow you to set up or put away the foldable rack quickly.

MEDIA GALLERY

FAQS

What is the recommended hardware to mount the PR-4100?

You will need eight (8) M10x75 lag bolts and eight (8) M10 washers to mount the wooden stringers to the wall. Then use the eight (8) M16x80 bolts and eight (8) M16 washers to mount the brackets to the wooden stringer. To mount to a concrete wall, use the M10x90 expansion bolts provided in the hardware pack.
Where do you recommend purchasing a stringer?

The rack does not come with a stringer. Your local hardware store should have a wood stringer available.
What do you recommend purchasing for the stringer?

The “stringer” is the wood mounted onto the wall/studs that you affix the rack to. Create a stringer using two wooden pieces with the following dimensions: 2x10x56”. We also suggest eight (8) lag bolts and washers, M10x1.50, L75 to securely mount the stringers on studs.
Will the PR-4100 still work if my garage isn’t level?

Yes. Although there is minimal vertical play in the hinges, we recommend mounting the rack fully assembled in the folded position to ensure it doesn’t get stuck while folding it back in. Vice versa, you may want to start assembling it in the open position. Using a couple of ¼ shims under the uprights during assembly can help.
Are the ISO Arms compatible with the PR-4100?

Technically yes, but we do not recommend using this attachment, as it could possibly lead to wall damage. The spacing of the brackets on the PR-4100 also limits the functional range of the ISO Arms .
What is the standard recommended spacing for the bottom stringer to the ground?

7-8" with the bracket being 9.5” off the ground for optimal stability.
Can I do kipping pull-ups and muscle-ups on the PR-4100?

Yes, but we recommend the 41” depth option for people performing kipping pull-ups or muscle-ups because of the body movement (out/back or in/out). The built-in pull-up bar is 1.25”.
Can you add spotter arms to the PR-4100?

Yes. If you purchase the spotter arms , it is important to make sure the rack is properly secured into your wall, as the weight on the arms could possibly cause separation from the wall if the rack is not properly mounted.

PR-4100 Folding Squat Rack image 1

PR-4100 Folding Squat Rack image 2

PR-4100 Folding Squat Rack image 3

PR-4100 Folding Squat Rack image 4

PR-4100 Folding Squat Rack image 5
